Frame: 355~900mm;
Power: 160kW~4500kW
Frequency: 50~100Hz
Voltage: 3000V~11000V
Poles：2~10P
Protection grade: IP54/IP55
Cooling method: IC416/IC516
Explosion proof： Ex d ⅠMb、Ex d ⅡA T4 Gb、Ex d ⅡB T4 Gb
YBBP355-560 series of high-voltage explosion-proof variable-frequency three-phase asynchronous motor is a new product developed by our company according to market demand. It can be used with frequency converter to achieve smooth and stepless in a wide range Speed regulation, the frequency range of 5-50Hz is constant torque speed regulation, and the frequency range of 50-100Hz (2P motor is 50-60Hz) is constant power speed regulation. It is an ideal drive product that meets the need for speed control equipment in explosive gas environments such as factories and coal mines.
YBBP355-560 series motors fully consider the requirements of the driven equipment, frequency converter and control during the speed regulation process. They have low moment of inertia, wide adjustment band range, resistance to frequency converter dv/dt high frequency pulse harmonics, high efficiency and energy saving, low noise, long life, high reliability, suitable for variable frequency drive of constant torque, constant power, square torque and other loads.
Motors can be widely used in mining, machinery industry, petrochemical industry, power plants and other industrial and mining enterprises to drive various general machinery: such as compressors, water pumps, crushers, cutting machine tools, transport machinery and other mechanical equipment.
